HP ZBook Studio G5 Mobile Workstation
Smaller, faster and brighter than ever

Features:

HP's brightest 4K UHD laptop display

See your work in one billion vibrant colors on the HP DreamColor display with 600 nits of brightness. Master color-critical work with 100% Adobe RGB coverage that helps maintain perfect color every single time.

More powerful than ever before

Get ultra fast performance with the latest Intel Core™ i9 processors and 64 GB memory. Render photorealistic images with certified NVIDIA Quadro P2000 graphics - optimized for stability and peak performance with professional software apps.

HP's most secure mobile workstation

Protect your work with industry-leading security features. A touch of a button activates HP Sure View privacy screen to protect against visual hacking and RAID 1 maintains a backup copy of all your files in case you ever need it.

Featuring

• Be productive in any situation. Windows 10 Pro and powerful security, collaboration, and connectivity features from HP help you power through your day on the HP ZBook Studio.
• Do more at once with next-generation 6-core Intel Core™ i9 or Intel Xeon processors designed to handle complex, multi-threaded applications like Adobe Premier Pro.
• Seamlessly edit your designs and render multi-layered files with certified NVIDIA Quadro P2000 graphics, optimized for stability and performance with professional software apps.
• Create seamlessly. Save and access large files locally with up to 4 TB local NVMe storage, up to 21 times faster than standard HDD storage and six times faster than SATA SSD.
• Get remarkable, real time performance running multiple applications simultaneously with up to 64 GB RAM.
• Take your work on the road with up to 16 hours of battery life for maximum productivity. When you need it, recharge ultra-fast (50% in just 45 minutes).
• Travel anywhere with this powerful laptop that weighs only 4.4 pounds. Get a full-sized, backlit minor spill-resistant keyboard for worry-free, flexible working on-the-go.
• Take your work outdoors with the anti-glare display and built in ambient light sensor that dims or brightens based on your surroundings.
• Host virtual meetings with the HP Collaboration Keyboard, HP World Facing Microphone & optional web cam. Get premium audio with 4 speakers tuned by Bang & Olufsen & a discrete amp.
• Experience fast transfer and upload speeds with dual Thunderbolt™ 3 ports. Keep all your devices and peripherals connected with 2 USB 3.0, 1 HDMI and 1 SD card port.
• Confidently take your work anywhere knowing your HP ZBook Studio was built for 24 x 7 x 365 workloads and passed 14 rigorous military standard tests like shock, drop and dust.
• Innovative docking solution that takes you from laptop to desktop experience. Connect dual 4K UHD displays, charge your devices, take a conference call, and transfer data quickly.

Specifications:

HP ZBook Studio G5 Mobile Workstation Specifications
Available Operating system	Windows 10 Pro 64 – HP recommends Windows 10 Pro. Windows 10 Home 64 Windows 10 Pro for Workstations 64 Red Hat Enterprise Linux 7 - Web support only FreeDOS 2.0
Processor family	Intel Xeon processor (E-2176M, E- 2186M); 8th Generation Intel Core™ i9 processor (i9-8950HK); 8th Generation Intel Core™ i7+ processor (Core™ i7 and Intel Optane™ memory) (i7-8750H, i7-8850H); 8th Generation Intel Core™ i7 processor (i7-8750H, i7-8850H); 8th Generation Intel Core™ i5+ processor (Core™ i5 and Intel Optane™ memory) (i5-8300H, i5-8400H); 8th Generation Intel Core™ i5 processor (i5-8300H, i5- 8400H)
Available Processors	Intel Xeon E 2186M vPro™ with Intel UHD Graphics P630 (2.9 GHz base frequency, up to 4.8 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores) Intel Xeon E 2176M vPro™ with Intel UHD Graphics P630 (2.7 GHz base frequency, up to 4.4 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores) Intel Core™ i9 8950HK with Intel UHD Graphics 630 (2.9 GHz base frequency, up to 4.8 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores) Intel Core™ i7 8850H vPro™ with Intel UHD Graphics 630 (2.6 GHz base frequency, up to 4.3 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores) Intel Core™ i7-8750H with Intel UHD Graphics 630 (2.2 GHz base frequency, up to 4.1 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores) Intel Core™ i5 8400H vPro™ with Intel UHD Graphics 630 (2.5 GHz base frequency, up to 4.2 GHz with Intel Turbo Boost Technology, 8 MB cache, 4 cores) Intel Core™ i5-8300H with Intel UHD Graphics 630 (2.3 GHz base frequency, up to 4.0 GHz with Intel Turbo Boost Technology, 8 MB cache, 4 cores)
Maximum memory	64 GB DDR4-2667 non-ECC SDRAM; 32 GB DDR4-2667 ECC SDRAM; 32 GB DDR4-2667 non-ECC SDRAM Transfer rates up to 2667 MT/s.
Memory slots	2 SODIMM
Internal storage	up to 2 TB 5400 rpm SATA 500 GB up to 1 TB 7200 rpm SATA 500 GB 7200 rpm SATA SED 500 GB 7200 rpm SATA FIPS 140-2 SED 500 GB up to 2 TB SATA SSHD 256 GB up to 1 TB SATA SSD 256 GB M.2 SATA SED SSD 256 GB up to 2 TB PCIe NVMe™ M.2 SSD 256 GB up to 512 GB PCIe NVMe™ M.2 SED SSD 2 x 1 TB up to 2 x 2 TB PCIe NVMe™ M.2 SSD
Display	HP DreamColor 15.6" diagonal 4K IPS anti-glare LED-backlit, 600 cd/m², 100% AdobeRGB (3840 x 2160) 15.6" diagonal 4K IPS eDP + PSR anti-glare LED-backlit and ambient light sensor, 400 cd/m² (3840 x 2160) 15.6" diagonal FHD IPS eDP + PSR anti-glare LED-backlit with ambient light sensor, 400 cd/m² (1920 x 1080) HP Sure View 15.6" diagonal FHD IPS eDP + PSR LED-backlit touch screen with Corning Gorilla Glass 4, 650 cd/m² (1920 x 1080)
Available Graphics	Integrated: Intel UHD Graphics 630; Intel UHD Graphics P630 Discrete: NVIDIA Quadro P1000 (4 GB GDDR5 dedicated); NVIDIA Quadro P2000 (4 GB GDDR5 dedicated) (Intel UHD Graphics 630 integrated on Core™ i7, Core™ i5 and Core™ i9 processors. Intel UHD Graphics P630 integrated on Xeon processors.)
Audio	HP tuned Bang & Olufsen, quad stereo speakers, HP World Facing Microphone supporting HP Noise Reduction Software, keyboard functions keys for volume up and down, combo microphone/headphone jack, HD audio, HP Clear Sound Amp
Communications	WLAN: Intel Dual Band Wireless-AC 9560 802.11ac (2x2) Wi-Fi and Bluetooth 5.0 Combo Intel Dual Band Wireless-AC 9560 802.11ac (2x2) Wi-Fi and Bluetooth 5.0 Combo, non-vPro™ ; (Optional Near Field Communication (NFC) module)
Expansion slots	1 UHS-II SD card reader (SD supports next generation secure digital and is backward compatible to SDHC, SDXC)
Ports and Connectors	Left side: 1 USB 3.0 (charging) Right side: 1 HDMI 1.4; 1 headphone/microphone combo; 1 power connector; 1 RJ-45; Ultra Slim Dock Connector; 1 USB Type-C™ (Thunderbolt™ 3, USB 3.1)
Input devices	HP Collaboration Keyboard, full-size, spill-resistant, backlit, with drain and DuraKeys, clickpad with image sensor and glass surface, multi-touch gestures and taps enabled; Image sensor clickpad with on/off button, two-way scroll, gestures, two buttons;
Camera	HP Privacy HD IR Camera 720p, face authentication with Windows Hello
Available Software	Bing search for IE11; Buy Office; HP ePrint Driver + JetAdvantage; HP Hotkey Support; HP Noise Cancellation Software; HP Performance Advisor; HP Recovery Manager; HP Remote Graphics Software; HP Support Assistant; HP Velocity; Skype for Business Certified; HP LAN-WLAN Protection; HP JumpStart; HP Client Security Suite Gen4
Security management	Absolute persistence module; Common Criteria EAL4+ Augmented Certified Discrete TPM 2.0 Embedded Security Chip; DriveLock and Automatic DriveLock; HP Device Access Manager; HP FingerPrint Sensor; HP Password Manager; HP Power On Authentication; HP Security Manager; Pre-boot authentication; HP Sure Click; Measured Boot; HP BIOS Config Utility (BCU); HP Client Catalog; HP Driver Packs; HP System Software Manager (SSM); HP Manageability Integration Kit Gen2; HP BIOSphere with Sure Start Gen4; HP Secure Disk Erase; HP Host Based Mac Address; Windows Defender
Power	150 W Slim Smart external AC power adapter
Battery type	HP Long Life 6-cell, 95.6 Wh Li-ion polymer; HP Long Life 4-cell, 64 Wh Li-ion polymer
Dimensions	14.17 x 10 x 0.35 to 0.69 in (front to rear)
Weight	Starting at 4.4 lb;
Environmental	Low halogen
Energy efficiency compliance	ENERGY STAR certified and EPEAT registered configurations available
Warranty	3 year or 1 year limited warranty options available, depending on country. Batteries have the same 1 year or 3 year limited warranty as the platform. 24/7 operation will not void the HP warranty. Optional HP Care Pack Services are extended service contracts which go beyond your standard limited warranties.

Image Gallery:

Documentation:

Download the HP ZBook Studio G5 Mobile Workstation Datasheet (.PDF)
