HP EliteDesk 800 G4 Small Form Factor PC
Security, manageability, and performance in a modern compact design

Overview:

Powered for the enterprise, the HP EliteDesk 800 SFF is one of our most secure and manageable PCs featuring high performance and expandability in a space-saving, stylishly designed chassis for the modern workplace.

Security, manageability, and performance in a modern compact design

• Windows 10 Pro
• HP Sure Start Gen4

Features:

Ready for virtul reality

High-performance users will enjoy huge expansion, powerful 8th Gen Intel Core™ processors , and Intel Optane™ memory . Amplify performance with optional 95W processors , and Thunderbolt™.

Expansion that expands your investment

The HP EliteDesk 800 SFF sets a new standard for expandability with four bays and four slots, plus three additional M.2 slots, and plenty of configurable ports.

Strong security, powerful manageability

Protect your PC against the evolving malware threats of the future, with selfhealing, hardware-enforced, and manageable security solutions from HP. From the BIOS to the browser HP Sure Start Gen4 and HP Sure Click help secure your PC.

Configurable ports for displays or Thunderbolt

Configure a rear I/O port for customizable display connections with your choice of VGA, DisplayPort™, HDMI or USB Type-C™ with DisplayPort™. Or, choose Thunderbolt™ for high-speed file transfer.

Featuring

• Power through your day with Windows 10 Pro with built-in security, collaboration, and connectivity.
• Protect the firmware that antivirus can’t reach! The hardware-enforced selfhealing protection offered by HP Sure Start Gen4 automatically recovers the BIOS from malware, rootkits, or corruption.
• Keep your critical applications and processes running even if malware tries to shut them down with self-healing protection.
• Help protect your PC from websites and in-browser .pdf files infected with malware, ransomware, or viruses with HP Sure Click.
• Quickly and securely restore PCs to the latest image using a network connection with HP Sure Recover.
• Improve the quality and security of custom Windows images with HP Image Assistant Gen3 which assists ITDMs with image creation, identifies problems, and provides recommendations and remediation.
• The HP Manageability Integration Kit helps speed up image creation and management of hardware, BIOS, and security through Microsoft System Center Configuration Manager.
• Fortify your security with up to three authentication factors.

Specifications:

HP EliteDesk 800 G4 Small Form Factor Specifications
Operating system	Windows 10 Pro 64 – HP recommends Windows 10 Pro. Windows 10 Pro 64 (National Academic only) FreeDOS 2.0
Processor Family	8th Generation Intel Core™ i3 processor (i3-8100, i3-8300); 8th Generation Intel Core™ i5 processor (i5-8500, i5-8600, i5-8600K); 8th Generation Intel Core™ i7 processor (i7-8700, i7-8700K); 8th Generation Intel Core™ i7+ processor (i7-8700, i7-8700K); Intel Pentium processor (G5400, G5500 are Windows 10 only); 8th Generation Intel Core™ i5+ processor (i5-8500, i5-8600, i5-8600K)
Processors	Intel Core™ i7-8700 with Intel UHD Graphics 630 (3.2 GHz base frequency, up to 4.6 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores); Intel Core™ i3-8100 with Intel UHD Graphics 630 (3.6 GHz, 6 MB cache, 4 cores); Intel Core™ i7-8700K with Intel UHD Graphics 630 (3.7 GHz base frequency, up to 4.7 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores); Intel Core™ i5-8600K with Intel UHD Graphics 630 (3.6 GHz base frequency, up to 4.3 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Core™ i5-8500 with Intel UHD Graphics 630 (3 GHz base frequency, up to 4.1 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Pentium Gold G5400 with Intel UHD Graphics 610 (3.7 GHz, 4 MB cache, 2 cores); Intel Core™ i5-8600 with Intel UHD Graphics 630 (3.1 GHz base frequency, up to 4.3 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Core™ i3-8300 with Intel UHD Graphics 630 (3.7 GHz, 8 MB cache, 4 cores); Intel Pentium Gold G5500 with Intel UHD Graphics 630 (3.8 GHz, 4 MB cache, 2 cores); Intel Core™ i7+ 8700 (Core™ i7 and 16 GB Intel Optane™ memory) (3.2 GHz base frequency, up to 4.6 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores); Intel Core™ i5+ 8600 (Core™ i5 and 16 GB Intel Optane™ memory) (3.1 GHz base frequency, up to 4.3 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Core™ i5+ 8500 (Core™ i5 and 16 GB Intel Optane™ memory) (3 GHz base frequency, up to 4.1 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Core™ i5+ 8600K (Core™ i5 and 16 GB Intel Optane™ memory) (3.6 GHz base frequency, up to 4.3 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Core™ i7+ 8700K (Core™ i7 and 16 GB Intel Optane™ memory) (3.7 GHz base frequency, up to 4.7 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores)
Chipset	Intel Q370
Form Factor	Small form factor
Maximum Memory	64 GB DDR4-2666 SDRAM Transfer rates up to 2666 MT/s.
Memory slots	4 DIMM
Internal Storage	500 GB up to 1 TB 7200 rpm SATA up to 2 TB 5400 rpm SATA up to 500 GB SATA SED Opal 2 HDD up to 500 GB 7200 rpm SATA FIPS SED 256 GB up to 512 GB SATA SED Opal 2 TLC SSD 256 GB up to 512 GB SATA FIPS SSD 128 GB up to 512 GB PCIe NVMe™ M.2 SSD 128 GB up to 1 TB PCIe NVMe™ TLC M.2 SSD 256 GB up to 512 GB PCIe NVMe™ SED Opal 2 TLC M.2 SSD
Additional storage	5-in-1 SD card reader
Optical drive	HP 9.5 mm Slim DVD-Writer
Available Graphics	Integrated: Intel UHD Graphics 630; Intel UHD Graphics 610 Discrete: NVIDIA GeForce GT 730 (2 GB DDR5 dedicated); AMD Radeon™ R7 430 Graphics (2 GB GDDR5 dedicated); NVIDIA Quadro P400 (2 GB GDDR5 dedicated)
Audio	Conexant CX20632 codec, universal audio jack, headset and headphone front ports (3.5 mm), multi-streaming capable
Expansion Slots	1 M.2 2230; 2 M.2 2230/2280; 1 PCIe 3.0 x16; 1 PCIe 3.0 x16 (wired as x4); 2 PCIe 3.0 x1 (1 PCIe M.2 2230 slot for WLAN and 2 PCIe M.2 2230/2280 slot for storage.)
Ports and Connectors	Front: 1 headphone; 1 headset connector; 1 USB 2.0; 1 USB 2.0 (fast charging); 1 USB Type-C™ (charging); 2 USB 3.1 Gen 2 Rear: 1 audio-in; 1 audio-out; 1 power connector; 1 RJ-45; 2 USB 2.0; 2 DisplayPort™ 1.2; 2 USB 3.1 Gen 1; 2 USB 3.1 Gen 2 Optional: 1 DisplayPort™ 1.2; 1 HDMI 2.0; 1 serial; 1 USB 3.1 Type-C™ Gen 1 (DisplayPort™); 1 VGA
Input devices	HP Conferencing Keyboard; HP PS/2 Business Slim Keyboard; HP PS/2 Keyboard; HP USB and PS/2 Washable Keyboard; HP USB Business Slim Keyboard; HP USB Keyboard; HP USB Smart Card (CCID) Keyboard; HP Wireless Business Slim Keyboard and Mouse Combo; HP Wireless Collaboration Keyboard ; HP PS/2 Mouse; HP USB 1000 dpi Laser Mouse; HP USB Antimicrobial Mouse; HP USB Hardened Mouse; HP USB Optical Mouse; HP USB Premium Mouse
Communications	LAN: Integrated Intel I219LM GbE LOM; Intel I210-T1 PCIe GbE; WLAN: Intel Dual Band Wireless-AC 9560 802.11ac (2x2) and Bluetooth 5 M.2, non-vPro™; Intel Dual Band Wireless-AC 9560 802.11ac (2x2) and Bluetooth 5 M.2, vPro
Drive Bays	1 slim ODD; One 2.5" HDD; Two 3.5" HDD
Environmental	Operating temperature: 10 to 35°C; Operating humidity: 10 to 90% RH
Available Software	Absolute Persistence module; HP Hotkey Support; HP Noise Cancellation Software; HP Support Assistant; Native Miracast Support; HP Wireless Wakeup; Buy Office (sold separately); HP Sure Recover; HP JumpStarts
Security management	DriveLock; HP BIOSphere; HP Password Manager; HP Power On Authentication; Intel Identity Protection Technology (Intel IPT); Power-on password (via BIOS); RAID configurations; Removable media write/boot control; SATA port disablement (via BIOS); Setup password (via BIOS); Support for chassis padlocks and cable lock devices; USB enable/disable (via BIOS); Solenoid lock and hood sensor; HP Client Security Suite Gen 4; HP Sure Start Gen 4; HP Sure Run; Parallel enable/disable (via BIOS); Serial enable/disable (via BIOS); Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified)
Management features	HP BIOS Config Utility (download); HP Client Catalog (download); HP Driver Packs (download); HP System Software Manager (download); Ivanti Management Suite; HP Management Integration Kit for Microsoft System Center Configuration Management Gen 2
Power	250 W internal power supply, up to 92% efficiency, active PFC
Dimensions (W X D X H)	3.94 x 13.3 x 12.13 in 10 x 33.8 x 30.8 cm
Weight	14.79 lb 6.71 kg (Exact weight depends on configuration.)
Energy efficiency compliance	ENERGY STAR certified; EPEAT Gold
Environmental specifications	Low halogen
Warranty	3 year (3-3-3) limited warranty and service offering includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.

Image Gallery:

Documentation:

Download the HP EliteDesk 800 Small Form Factor PC Datasheet (.PDF)
